The Whirlpool Ultimate Care II washing machine has a large capacity drum and numerous wash options. It also comes equipped with Whirlpool's AccuWash temperature sensor, which controls the temperature of the water coming into the machine. EnCA Whirlpool Canada may contact me, including by electronic mail, about its special offers, exclusive events, brands, products and services. You can withdraw your consent at any time. All gathered information is governed by our. For more information and a list of brands, click here or Contact Us. Troubleshooting guide with step by step instructions for repairing Whirlpool direct drive washers Appliance information center. Free repair help and troubleshooting.
Written by John Albers; Updated July 21, 2017Related Articles
- 1 What Would Make a Dryer Stop Working?
- 2 The Kenmore 90 Dryer Stopped Running
- 3 Troubleshoot a GEW9250PW0 Duet Dryer
- 4 Tell if the Door Relay Goes Bad on a Dryer
Tumbler Won't Spin
If the tumbler won't spin when it operates, unplug it and try to move the tumbler by hand. If it won't budge, then something is jammed. If it turns with no resistance at all, you may have a problem with your drive belt. If it turns with consistent, minor resistance then the problem may be electrical. Follow the instructions of your user's manual to remove the tumbler so the belt drive and motor are visible. Inspect the drive belt. If it hangs loose, it needs to be tightened. If it is frayed or has worked its way up the drive shaft, it should be replaced. Try to turn the driveshaft leading from the motor by hand. If it won't budge, then your motor is seized and needs to be replaced. If nothing is wrong with the belt or the motor, then the problem is in the control circuit. It may be damaged, preventing the motor from engaging.
Dryer Stopped Working Mid-Cycle
If the dryer stops working mid-cycle and will not respond to any of the control functions, unplug it, empty it of clothing and pull it away from the wall. Remove the service panel on the back and open it. Be mindful of smoke and the smell of burnt plastic; these are good indications that something carrying electricity has just died. This particular model of dryer is notorious for its electrical plug and power block, which should be the black box near the bottom in the back. If there are any signs of charring, melting, or discoloration, the power cord and block are your culprits. These can be replaced with a new power cord and terminal-connection wire kit obtained at any hardware store. If there is no indication of electrical damage, the problem is likely the control circuit set underneath the control board on the face of the dryer. Such boards can't be fixed, only replaced--a task best left to a certified repairman.
Dryer Won't Stop Running
Ultimate Car II Dryers are fitted with a mechanical timer that sends an impulse to the control circuit board to stop running once the set amount of drying time has elapsed. This is because, should an electronic timer fail, this would necessitate the replacement of the entire circuit board. Confirm that the mechanical timer is indeed broken by opening the dryer's door. If the dryer stops, the circuit board is working fine and is not the problem. Simply slide off the protective faceplate of the dryer, unscrew the control board beneath, and flip it over. Connected to the back of the timer's knob should be a small round device with two wires running to the circuit board within the body of the dryer. Unscrew this device from the back of the knob and disconnect the wires. A replacement timer costs a few dollars and should screw into place without trouble. Reconnect the wires and put the dryer back together. It should work fine now.
About the Author
John Albers has been a freelance writer since 2007. He's successfully published articles in the 'American Psychological Association Journal' and online at Garden Guides, Title Goes Here, Mindflights Magazine and many others. He's currently expanding into creative writing and quickly gaining ground. John holds dual Bachelor of Arts degrees from the University of Central Florida in English literature and psychology.
Photo Credits
- http://i21.ebayimg.com/01/c/000/77/50/2c4a_32.JPG
Choose Citation Style
Whirlpool Ultimate Care Ii Washer Repair Manual
The Whirlpool Ultimate Care II washer has a lid switch assembly installed inside the washer cabinet. When you shut the lid on the washer, a tab on the lid pushes down the switch to let the washer know it can fill with water, agitate and spin. Damaged to the switch caused by slamming the washer lid closed or damage to the switch’s internal connectors can keep the washer from washing your clothes. A damaged switch could even keep the washer from draining.
1
Reach behind the Whirlpool Ultimate Care II washer to pull the washer’s power supply cord from the wall outlet. Slide the washer forward about six inches.
2
Look behind the control panel for the two screws at each end of the panel. The screws set in channels at in the ends of the panel. Use a magnetized-tip Phillips screwdriver to remove the screws so you can lift the screws from the channels.
3
Pull up on the front of the control panel. Rotate it over the back of the Whirlpool washer to expose the spring clips holding the washer’s cabinet to the rear cabinet wall and the lid switch wire harness.
4
Push the end of a flat-head screwdriver into the hole in the cabinet holding the spring clips. Continue to push the end of the screwdriver down while pushing the handle of the screwdriver toward the rear cabinet wall. This pops the springs from the top of the Whirlpool washer’s cabinet. Grab the wire harness with your fingers and pull it from the connector on the lid switch.
5
Spread an old blanket over the floor. Grab both sides of the Whirlpool Ultimate Care II cabinet. Tilt the cabinet forward and slide it off the bottom support frame. Lay the front of the cabinet on the old blanket.
6
Look beneath the lid for a green ground wire attached to the washer cabinet. Remove the screw holding the green wire to the cabinet. Place the screw in a safe location.
7
Open the lid and look for the two screws next to the lid switch opening. Remove the two screws holding the screws. Place the lid switch screws in a safe location.
8
Unsnap the wires attached to the lid switch from the metal retainers along the edge of the cabinet. Use pliers to squeeze the side tabs on the lid switch connector to release it from the hole in the cabinet. Discard the old lid switch.
9
Snap the new lid switch connector into the opening in the cabinet. Secure the lid-switch wires beneath the metal retainers along the edge of the cabinet.
10
Hold the new switch against the cabinet while you secure it with the lid switch screws. Use the screw you removed from the green ground wire to secure the new ground wire to the washer cabinet.
11
Whirlpool Ultimate Care 2 Manual
Reverse the steps you used when disassembling the Whirlpool Ultimate Care II washer to reassemble it. Push the washer back in its original position and plug it back into the wall outlet.
Things You Will Need
Whirlpool Ultimate Care Ii Washing Machine Manual
- Phillips screwdriver with magnetized tip
- Flat-head screwdriver
- Old blanket
- Pliers
